Description
Ellies Outdoor UHF Digital Terrestrial 4 Element TV Antenna – Wideband Grid 4 Element Panel UHF Channels 21 to 68, Powder Coated Reflector, F-Connector Coax Cable Female Connection, Frequency 470 – 860 MHz, FB Ratio 28 dB, Beamwidth 49H and 30V Degrees, Retail Box, 1 year Limit warranty
Product Overview
The Ellies Outdoor UHF Digital Terrestrial 4 Element TV Antenna offers the best solution that can receive the entire Digital Terrestrial Television UHF band preventing receive antenna changes when transmitter UHF channels are added or moved. F-Connector coax cable connection at antenna allows quick and easy cable installation and improved performance over traditional TV antenna “saddle” connectors.
The Ellies Outdoor UHF Digital Terrestrial 4 Element TV Antenna offers the best solution that can receive the entire Digital Terrestrial Television UHF band preventing receive antenna changes when transmitter UHF channels are added or moved. F-Connector coax cable connection at antenna allows quick and easy cable installation and improved performance over traditional TV antenna “saddle” connectors.
Delivered in a reduced size configuration and is clicked open into full dimensions at installation with one very easy operation and no tools. Powder coated reflector, UV stabilised plastics and galvanised mast mounting hardware allow longer service life. Grid Panel antenna is significantly more resistant to damage by nesting birds and rotation about mast due to wind and is less obtrusive than traditional “Yagi” and LPDA and other horizontally long types of antennas. Grid Panel antenna can be elegantly/easily mounted on the outside of a house wall allowing an installation that is not easily visible from outside the property. (Location/direction and distance to transmitter permitting)
Please Note Wall Mounting Bracket and Coax cabling are not included must be purchased separately
Specifications
• Stock Code ELBPAAG
• Description Ellies Outdoor UHF Grid Digital Terrestrial 4 Element TV Antenna
• Product Type Wideband Grid 4 Element Panel UHF Channels 21 to 68- Frequency 470 – 860 MHz
• Powder Coated Reflector
• UV Stabilised Plastics And Galvanised
• Less Obtrusive Than Traditional “Yagi” And LPDA And Other Horizontally Long Types Of Antennas.
• Mast Mounting Hardware Allow Longer Service Life.
• F-Connector Coax Cable Female Connection
• Frequency 470 – 860 MHz
• FB Ratio 28 dB
• Beamwidth 49H and 30V Degrees
• Product dimensions(W) Width: 390mmx (H) Height: 500mmx (D) Depth: 250mm
• Wall Mounting Bracket and Coax cabling are not included must be purchased separately
• Weight: 2.0Kg
Specifications
• Stock Code ELBPAAG
• Description Ellies Outdoor UHF Grid Digital Terrestrial 4 Element TV Antenna
• Product Type Wideband Grid 4 Element Panel UHF Channels 21 to 68- Frequency 470 – 860 MHz
• Powder Coated Reflector
• UV Stabilised Plastics And Galvanised
• Less Obtrusive Than Traditional “Yagi” And LPDA And Other Horizontally Long Types Of Antennas.
• Mast Mounting Hardware Allow Longer Service Life.
• F-Connector Coax Cable Female Connection
• Frequency 470 – 860 MHz
• FB Ratio 28 dB
• Beamwidth 49H and 30V Degrees
• Product dimensions(W) Width: 390mmx (H) Height: 500mmx (D) Depth: 250mm
• Wall Mounting Bracket and Coax cabling are not included must be purchased separately
• Weight: 2.0Kg
