Manhattan VGA +R/L Audio to HDMI Converter Retail Box Limited Lifetime Warranty
Converts PC Audio/Video to HDMI
Converts PC Audio/Video to HDMI
Product Overview
Converts analog PC-based A/V signals into HDMI
The MANHATTAN VGA to HDMI Converter translates analog PC audio/video signals and transmits digital output to HDMI projectors, flat-panel displays, televisions and other similar devices. Built-in circuitry allows digital media enthusiasts to easily distribute and enjoy PC-based multi-media content on high-definition displays and TVs while maintaining simultaneous A/V reception at the source PC. Its high bandwidth capability supports up to 1280 x 1024 and 1080p to serve a wide range of resolutions in many PC and high-definition applications including training, retail and tradeshow settings. With quick Plug and Play installation and Windows and Mac compatibility, the MANHATTAN VGA to HDMI Converter requires no software or complicated configuration to convert and deliver digital content stored on desktop and notebook computers.
Features
Specification
- Standards and Certifications
- HDMI 1.2a
- CE
- FCC
General:
- Supports HDCP pass-through
- Computer-to-video converter range: up to 5 m (16 ft.)
- Video converter-to-monitor range: up to 5 m (16 ft.)
- Power: 5 V DC / 1 A; cable with ferrite core, 1.2 m (4 ft.)
Connections:
- Input: (1) VGA DB15 male and (2) RCA audio left/right female
- Output: (1) HDMI female
Signal input/output:
- Input video signal: 0.5 – 1.0 V p-p
- Input DDC signal: 5 V p-p (TTL)
- Maximum single link range: 1280 x 1024 and 1080p
- Output video: HDMI 1.2a
- Frequency: 1.65 Gbps / 165 MHz
Video resolutions:
- VGA: 640 x 480, 800 x 600, 1024 x 768, 1280 x 720, 1280 x 768, 1280 x 960, 1280 x 1024
- DTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p
Physical:
- LED indicators: power and port connection
- Dimensions: 89 x 29 x 68 mm (3.5 x 1.1 x 2.7 in.)
- Weight: 119 g (4.2 oz.)
Package contents:
- VGA to HDMI Converter
- Power adapter and user manual
