Description
TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+ , Retail Box , 2 year Limited Warranty
Product Overview
The TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+ (TL-SG1016PE) is designed to enhance your network’s efficiency and flexibility. It features 16 Gigabit Ethernet ports, with 8 ports supporting Power over Ethernet (PoE+) for seamless power and data transmission. This switch is ideal for expanding wired networks in small to medium-sized businesses, offering a total PoE power budget of 110W to support various devices.
Specifications
•Product code:TL-SG1016PE
•Description: TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+
•Standards and Protocols IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
•Interface 16 10/100/1000Mbps RJ45 Ports
•AUTO Negotiation/AUTO MDI/MDIX
•Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
•EIA/TIA-568 100Ω STP (maximum 100m)
•100BASE-TX: UTP category 5, 5e cable (maximum 100m)
•EIA/TIA-568 100Ω STP (maximum 100m)
•1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
•EIA/TIA-568 100Ω STP (maximum 100m)
•Fan Quantity 1
•Physical Security Lock Yes
•PoE Ports (RJ45) Standard: 802.3 at (30W)
•PoE Ports: Port 1- Port 8
•Total PoE Power Budget: 110W
•Dimensions ( W x D x H ) 11.6 × 7.1 × 1.7 in.
•(294 × 180 × 44 mm)
•Mounting 13″ and 19″ 1U rack mountable
•Max Power Consumption 14.7W (no PD load)
•131.4W (with 110W PD load)
•Max Heat Dissipation 50.2 BTU/h (no PD load)
•448.4 BTU/h (with 110W PD load)
•Switching Capacity 32Gbps
•Packet Forwarding Rate 23.8Mbps
•MAC Address Table 8K
•Packet Buffer Memory 4.1Mb
•Jumbo Frame 9KB
•Quality of Service Support Port-Based/802.1p/DSCP priority
•Support 4 priority queues
•Rate Limit
•Storm Control
•L2 Features IGMP Snooping V1/V2/V3
•Link Aggregation
•Port Mirroring
•Cable Diagnostics
•Loop Prevention
•VLAN Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
•MTU/Port/Tag VLAN
•Management Web-based GUI
•Easy Smart Configuration Utility
•POE Auto Recovery
•Transmission Method Store-And-Forward
