Description
TP-Link ARCHER-TX20E WiFi and Bluetooth PCIe Card for Desktop PC – Bluetooth 5.2, WPA3, 802.11ax Dual Band Wireless Adapter with MU-MIMO, Ultra-Low Latency, Retail Box , 1 year Limited Warranty
Product Overview
Upgrade your desktop with the TP-Link Archer TX20E. Enjoy lightning-fast Wi-Fi speeds with the latest Wi-Fi 6 technology and a wider range thanks to its high-gain antennas.Benefit from improved security with WPA3 encryption and experience faster connections with Bluetooth 5.2. Easily boost your PC’s wireless performance with this powerful adapter.
Features
•Unrivalled Wi-Fi 6 Speed Breaks the gigabit barrier with speed up to 1201 Mbps (5 GHz) + 574 Mbps (2.4 GHz)
•Bluetooth 5.2 The latest Bluetooth technology achieves 2× Faster Speed and 4× Broader Coverage than BT 4.2
•Backward Compatibility Full support for 802.11ax/ac/a/b/g/n standards
Specifications
•Product code:ARCHER-TX20E
•Description: TP-Link ARCHER-TX20E WiFi and Bluetooth PCIe Card for Desktop PC
•Dimensions 4.76 × 3.09 × 0.82 in
•(120.8 × 78.5 × 20.9 mm)
•Antenna Type Two High-Gain Dual Band Antennas
•Chipset Realtek Wi-Fi 6 Chipset
•Wireless Standards IEEE 802.11ax/ac/n/a 5 GHz
•IEEE 802.11ax/n/g/b 2.4 GHz
•Bluetooth 5.2
•WLAN Signal Rate 5 GHz
•11ax: Up to 1201 Mbps(dynamic)
•11ac: Up to 867 Mbps(dynamic)
•11n: Up to 300 Mbps(dynamic)
•11a: Up to 54 Mbps(dynamic)
•2.4 GHz
•11ax: Up to 574 Mbps(dynamic)
•11n: Up to 300 Mbps(dynamic)
•11g: Up to 54 Mbps(dynamic)
•11b: Up to 11 Mbps(dynamic)
•WLAN Reception Sensitivity 5 GHz :
•11ax HE80: -57.0dBm
•11ax HE40: -60.0dBm
•11ax HE20: -63.0dBm
•11ac VHT80: -59.5dBm
•11ac VHT40: -62.5dBm
•11ac VHT20: -67.5dBm
•11n HT40: -69.5dBm
•11n HT20: -72.5dBm
•11a 54Mbps: -74.0dBm
•11a 6Mbps: -94.5dBm
•2.4GHz :
•11ax HE40: -60.0dBm
•11ax HE20: -63.0dBm
•11n HT40: -69.5dBm
•11n HT20: -72.5dBm
•11g 54Mbps: -74.0dBm
•11b 11Mbps: -88.0dBm
•WLAN Transmit Power 5 GHz : 27dBm(FCC) / 23dBm(CE) (EIRP)
•2.4 GHz : 25dBm(FCC) / 20dBm(CE) (EIRP)
•WLAN Modes Infrastructure mode
•Package Contents Archer TX20E
•Two High-Gain Dual Band Antennas
